CQB medium fluoroplastic magnetic pump

CQB medium fluoroplastic magnetic pump

CQB medium fluoroplastic magnetic pump

CQB medium fluoroplastic magnetic pump
TECHNICAL DATA
Material: F46/HT200
DN: 32mm-80mm
PN: 16bar
Q: 12.5m³/h-50m³/h
H: 25m-38m
T: -20°C-200°C
P: 4kw-7.5kw

Send E-mail:Nancy@jnhgbf.com

Send Inquiry Get Latest Price
Join Us On Whatsapp:Click it to Join in

General Overview

General Overview

  • CQB medium-sized fluoroplastic magnetic pump is referred to as “CQB medium-sized magnetic pump” for short. It adopts magnetic coupling drive, and there is no dynamic sealing point. Therefore, it can prevent the general shaft drive centrifugal pump from running, emitting, dripping and leaking.
  • CQB medium-sized fluorine plastic magnetic pump flow parts are made of fluorine plastic and high-purity industrial ceramics, with excellent corrosion resistance and sealing performance. Therefore, this product is widely used in chemical industry, acid making, alkali making, smelting, rare earth, pesticide, dye, medicine, paper making, electroplating, electrolysis, pickling, radio, foil forming, scientific research institutions, national defense industry and other industries.
  • CQB medium-sized fluoroplastic magnetic pump can transport medium: transport any concentration of acid, alkaline, oil, rare and precious liquid, toxic liquid, volatile chemical medium. Especially the transportation of flammable, leaky and explosive liquid chemical medium.

Applicable fields Model parameters

N Model Rev =2900r/min   Medium density=1000kg/m³
Flow Pump head η Inlet Outlet Npsh Power Weight
(m³/h) (m) (%) (mm) (mm) (m) (kw) (kg)
1 CQB50-32-160B 12.5 32 40 φ50 φ32 3.5 4 110
2 CQB65-50-160B 20 25 38 φ65 φ50 4 4 100
3 CQB65-50-180F 20 38 46 φ65 φ50 5.5 5.5 120
4 CQB80-65-125F 50 20 51 φ80 φ65 4 7.5 95

Installation dimensions Size chart

N Model Installation dimensions
Outside and installing size Inlet flange size Exit flange size
L S f W T H h x c a b n-φd k g i n-φt
1 CQB32-20-160F 578 225 85 225 180 330 160 / 32 140 100 4-Ф13.5 20 100 75 4-Ф13.5
2 CQB40-25-160F 625 225 85 220 220 330 170 / 40 150 110 4-Ф13.5 25 115 85 4-Ф13.5
3 CQB50-32-160F 625 225 85 260 220 330 170 / 50 165 125 4-Ф17.5 32 140 100 4-Ф17.5
4 CQB50-32-160B 675 300 106 260 220 330 170 / 55 165 125 4-Ф17.5 32 140 100 4-Ф17.5
5 CQB65-50-125F 625 225 85 260 220 330 170 / 65 185 145 4-Ф17.5 50 165 125 4-Ф17.5
6 CQB65-50-150F 670 350 95 290 240 395 190 102 65 185 145 4-Ф17.5 50 165 125 4-Ф17.5
7 CQB65-50-160F 670 350 95 290 240 395 190 102 65 185 145 4-Ф17.5 50 165 125 4-Ф17.5
8 CQB65-50-160B 760 350 125 260 220 330 170 / 65 185 145 4-Ф17.5 50 165 125 4-Ф17.5
9 CQB65-50-180F 710 350 95 290 240 395 190 102 65 185 145 4-Ф17.5 50 165 125 4-Ф17.5
