JUY corrosion and wear resistant centrifugal pump

JUY corrosion and wear resistant centrifugal pump

JUY corrosion and wear resistant centrifugal pump

JUY corrosion and wear resistant centrifugal pump
TECHNICAL DATA
Material: UHMW-PE/HT200
DN: 12mm-100mm
PN: 16bar
Q: 0.5m³/h-120m³/h
H: 2m-55m
T: -20°C-120°C
P: 0.025kw-22kw

Send E-mail:xiaoyun@jnhgbf.com

Join Us On Whatsapp:Click it to Join in

General Overview

General Overview

  • The JUY wear-resisting liquid pump is referred to as “JUY liquid wear-resisting pump”. The overcurrent parts in contact with the conveying medium are made of ultra-high molecular polyethylene (UHMWPE) and reinforced polypropylene by the whole mould. The depth of the liquid is 1-2 meters.
  • JUY wear-resistant liquid pump has excellent wear-resistant performance, its temperature resistance, corrosion resistance, mechanical stability, wear resistance and economic operation costs have been recognized by users.

Applicable fields Model parameters

序号 Model Rev=2900r/min   Medium density=1000kg/m³
Flow Pump head Outlet (Rev) Power Weight
(m³/h) (m) (mm) (mm) (kW) (kg)
1 25JUY-3-5 3 5 φ25 2900 0.75 55
2 25JUY-3-10 3 10 φ25 2900 1.1 55
3 25JUY-5-15 5 15 φ25 2900 1.1 55
4 25JUY-5-20 5 20 φ25 2900 1.5 55
5 32JUY-5-25 5 25 φ32 2900 2.2 63
6 32JUY-10-10 10 10 φ32 2900 1.5 63
7 32JUY-10-15 10 15 φ32 2900 1.5 63
8 32JUY-15-15 15 15 φ32 2900 2.2 63
9 32JUY-10-20 10 20 φ32 2900 2.2 63
10 40JUY-10-30 10 30 φ40 2900 3 95
11 40JUY-15-20 15 20 φ40 2900 3 95
12 40JUY-15-28 15 28 φ40 2900 3 95
13 40JUY-20-10 20 10 φ40 2900 3 95
14 40JUY-20-20 20 20 φ40 2900 4 108
15 40JUY-20-25 20 25 φ40 2900 4 108
16 40JUY-30-15 30 15 φ40 2900 4 108
17 40JUY-20-30 20 30 φ40 2900 5.5 126
18 50JUY-30-15 30 15 φ50 2900 5.5 126
19 50JUY-30-20 30 20 φ50 2900 5.5 130
20 50JUY-30-25 30 25 φ50 2900 5.5 130
21 50JUY-30-30 30 30 φ50 2900 7.5 130
22 50JUY-40-10 40 10 φ50 2900 5.5 130
23 50JUY-40-15 40 15 φ50 2900 5.5 130
24 65JUY-40-15 40 15 φ65 2900 5.5 165
25 65JUY-40-20 40 20 φ65 2900 7.5 170
26 65JUY-45-25 45 25 φ65 2900 7.5 170
27 65JUY-50-8 50 8 φ65 2900 7.5 170
28 65JUY-45-30 45 30 φ65 2900 11 219
29 65JUY-50-25 50 25 φ65 2900 11 219
30 65JUY-60-20 60 20 φ65 2900 11 219
31 80JUY-60-30 60 30 φ80 2900 15 280
32 80JUY-80-30 80 30 φ80 2900 18.5 310
33 80JUY-100-30 100 30 φ80 2900 22 350
34 100JUY-100-26 100 26 φ100 2900 22 450
35 100JUY-90-30 90 30 φ100 2900 22 450
36 100JUY-120-25 120 25 φ100 2900 22 450
37 100JUY-130-23 130 23 φ100 2900 22 450
