JMC stainless steel magnetic pump

JMC stainless steel magnetic pump

JMC stainless steel magnetic pump

JMC stainless steel magnetic pump
TECHNICAL DATA
Material: 304/316L/HT200
DN: 20mm-125mm
PN: 16bar
Q: 2m³/h-200m³/h
H: 20m-80m
T: -50°C-260°C
P: 0.75kw-55kw

Send E-mail:xiaoyun@jnhgbf.com

Join Us On Whatsapp:Click it to Join in

General Overview

General Overview

  • JMC stainless steel magnetic drive pump, hereinafter referred to as “JMC stainless steel magnetic pump” provided using CFX, combining CFD analysis to calculate the performance of hydraulic model, flow components using high-quality stainless steel materials such as 304, 316 l, internal and external magnetic rotor with high magnetic energy product and high coercive force of rare earth permanent magnet manufacture, has high efficiency and energy saving, medium widely applicable, the advantages of high temperature resistant, strong magnetic, no demagnetization, application of magnetic coupling dynamic sealing contact transmission, a new type of high quality magnetic transmission centrifugal pump.
  • JMC stainless steel magnetic pump is fully sealed, no leakage, clean, environmental friendly, quiet and low vibration in operation. It is the preferred pump for conveying inflammable, explosive, corrosive and precious liquid. Because of energy saving, environmental protection, reliability and safety, and replace import to save a lot of costs for users. Widely used in chemical, alkali, petroleum, medicine, health, pesticide, paper, dye, sewage treatment and other fields.
  • JMC magnetic pump has high efficiency, energy saving, strong cavitation resistance and wide range of applicable temperature. It has the advantages of stable operation, low noise and vibration, high reliability, long life and so on. It is the ideal conveying equipment for alkali liquor, alcohol, various organic solvents and other media.

适用范围 Model parameters

N Model Rev=2900r/min   Medium density=1000kg/m³
Flow Pump head η Inlet Outlet Npsh Power Weight
(m³/h) (m) (%) (mm) (mm) (m) (kW) (kg)
1 JMC25-20-125 2 20 24 φ25 φ20 2 0.75 55
2 JMC25-20-160 2 32 22 φ25 φ20 2 1.1 60
3 JMC25-20-200 2 50 20 φ25 φ20 2 2.2 85
4 JMC32-20-125 3.6 20 19 φ32 φ20 2 1.1 60
5 JMC32-20-160 3.6 32 27 φ32 φ20 2 1.5 70
6 JMC32-20-200 3.6 50 24 φ32 φ20 2.5 3 100
7 JMC40-25-125 6.3 20 36 φ40 φ25 2.5 1.5 65
8 JMC40-25-160 6.3 32 33 φ40 φ25 2.5 2.2 75
9 JMC40-25-200 6.3 50 29 φ40 φ25 2.5 5.5 120
10 JMC40-25-250 6.3 80 25 φ40 φ25 2.5 7.5 165
11 JMC50-32-125 12.5 20 47 φ50 φ32 2.5 2.2 70
12 JMC50-32-160 12.5 32 43 φ50 φ32 2.5 4 120
13 JMC50-32-200 12.5 50 40 φ50 φ32 2.5 7.5 155
14 JMC50-32-250 12.5 80 35 φ50 φ32 2.5 11 220
15 JMC65-50-125 25 20 58 φ65 φ50 2.5 3 85
16 JMC65-50-160 25 32 50 φ65 φ50 2.5 5.5 135
17 JMC65-40-200 25 50 45 φ65 φ40 2.5 11 190
18 JMC65-40-250 25 80 40 φ65 φ40 2.5 15 250
19 JMC80-65-125 50 20 54 φ80 φ65 3 5.5 105
20 JMC80-65-160 50 32 52 φ80 φ65 3 11 170
21 JMC80-50-200 50 50 46 φ80 φ50 3 15 210
22 JMC80-50-250 50 80 43 φ80 φ50 3.5 30 360
23 JMC100-80-125 100 20 63 φ100 φ80 3.5 11 175
24 JMC100-80-160 100 32 50 φ100 φ80 3.5 15 215
25 JMC100-65-200 100 50 46 φ100 φ65 3.5 30 350
26 JMC100-65-250 100 80 43 φ100 φ65 4 45 480
27 JMC125-80-160 160 32 60 φ125 φ80 4 30 410
28 JMC125-100-200 200 50 55 φ125 φ100 4.5 55 590
